8 Frequency Scan Measurement
Marker Function
Key Path
Meas Setup, Detectors (Measure)
Notes Front panel only. The selected final detector is remembered even when not in the Detector Menu.
Preset Detector 1, not affected by Mode Preset, preset by Restore Mode Defaults.
State Saved Saved in instrument state.
Initial S/W Revision A.07.00
Dwell Time
Sets the dwell time for detectors
Key Path
Meas Setup, Detectors (Measure)
Remote Command
[:SENSe]:FSCan:FINal:DETector[1]|2|3:DWELl <dwell Time>
[:SENSe]:FSCan:FINal:DETector[1]|2|3:DWELl?
Example FSC:FIN:DET3:DWEL 300ms Set dwell time of detector 3 to 300 ms.
FSC:FIN:DET3:DWEL?
Notes Not affected by a Mode Preset, preset by a Restore Mode Defaults.
The minimum Dwell Time is coupled to the detector type:-
a) When the Quasi Peak detector is selected, the minimum Dwell Time is 0.5 ms.
b) When the EMI Average/ RMS Average detector is selected, the minimum Dwell Time is 0.1 ms.
c) When the Peak/ Negative Peak detector is selected, the minimum Dwell Time is depends on the
smallest RBW among ranges turned on in the Scan Table.
RBW≤ 10 Hz 10 ms
10 Hz< RBW< 100 Hz 1 ms
100 Hz< RBW< 200 Hz 1 ms
200 Hz < RBW<1 kHz 0.1 ms
1 kHz < RBW<100 kHz 0.1 ms
≥100 kHz 50 us
Dependencies This key is grayed out during final measurement. If the grayed out key is pressed, an advisory
message is generated. If the equivalent SCPI command is sent, this same message is generated as
part of a “–221, Settings conflict” warning.
Couplings If “Off” is selected for detector 1, this key is grayed out and shows 200 ms.
Preset 200 ms|1 s|1 s
State Saved Saved in instrument state.
Min 1 ms|1 s|1 s
Max 60 s
Default Unit s
Initial S/W Revision A.07.00
420 EMI Receiver Mode Reference
