11 APD Measurement
Meas Setup
Meas Setup
Displays a menu of keys that enable you to set up the measurement.
Key Path
Front-panel key
Notes Front panel only.
Initial S/W Revision A.13.00
Select Signal
Specifies the selected signal. The term “Selected signal” is used throughout this document to specify
which signal will be affected by the functions.
Key Path
Meas Setup, Signal List
Notes Front panel only. When Select Signal is the active function, press UP to go up in the signal list, and
press DOWN to go down in the list.
Couplings When the signal list is cleared, this value will reset to 0. Select Signal is auto coupled with
Frequency Scan and Monitor Spectrum Selected signal.
Preset If the signal list is empty, =0
If the signal list is not empty, = number of peaks in the signal list table
State Saved Saved in instrument state.
Min 0
Max Number of peaks in the signal list table.
Initial S/W Revision A.13.00
Meas Time
Specifies the measurement time for each sweep.
Key Path
Mode Setup
Remote Command
[:SENSe]:APD:SWEep:TIME <time>
[:SENSe]:APD:SWEep:TIME?
Example APD:SWE:TIME 500ms
APD:SWE:TIME?
Preset 100 ms
State Saved Saved in instrument state.
Min 10 ms
Max 120 s
Default Unit s
Initial S/W Revision A.13.00
940 EMI Receiver Mode Reference
