11 APD Measurement
FREQ Channel
Key Path
FREQ Channel
Remote Command
[:SENSe]:FREQuency:CENTer:STEP[:INCRement] <freq>
[:SENSe]:FREQuency:CENTer:STEP[:INCRement]?
[:SENSe]:FREQuency:CENTer:STEP:AUTO OFF|ON|0|1
[:SENSe]:FREQuency:CENTer:STEP:AUTO?
Example FREQ:CENT:STEP:AUTO ON
FREQ:CENT:STEP 500 MHz
FREQ:CENT UP increases the current center frequency value by 500 MHz
FREQ:CENT:STEP?
FREQ:CENT:STEP:AUTO?
Notes Preset and Max values are dependent on Hardware Options (503, 508, 513, 526)
Preset Auto
ON
State Saved Saved in instrument state
Min – ( the maximum frequency of the instrument). (that is, a 27 GHz max freq instrument has a CF step
range of +/– 27 GHz)
Max The maximum frequency of the instrument. (that is, a 27 GHz max freq instrument has a CF step
range of +/– 27 GHz)
Default Unit Hz
Status Bits/OPC
dependencies
non-overlapped
Initial S/W Revision A.07.00
Freq à Signal (Replace)
Replaces the frequency of the selected signal with the set Frequency. Trace, Disturbance level (E meas),
Probability of Time (ρ meas) and Delta To Limit values will be shown as “--“ to indicate that those values
are undefined. TimeStamp will be updated. Signal list will be re-sorted based on the auto sort setting.
Key Path
FREQ Channel
Remote Command
:CALCulate:APD:SLISt:REPLace <integer>
Example CALC:APD:SLIS:REPL 2 Replace Signal #2 with Freq
Notes If the signal list contains no data, an error is generated and this function cannot be performed.
If the selected signal is not in the list, an error is generated and this function cannot be performed.
Initial S/W Revision A.13.00
Freq à List (Append)
Append the set Frequency to the signal list. Trace, Disturbance level (E meas), Probability of Time (ρ meas)
and Delta To Limit values will be shown as “--“to indicate that those values are undefined.
916 EMI Receiver Mode Reference
