Keysight x-series User Reference Guide

7 Trigger Functions
Trigger
EDGE EVM EDGE/GSM RFB IQMag
EDGE ORFS EDGE/GSM Periodic Timer IQ not
supported
Combined
WCDMA
WCDMA IMM IQ not
supported
Combined
GSM
EDGE/GSM RFB IQ not
supported
List Power
Step
WCDMA,
EDGE/GSM
IMM IQ not
supported
Transmit
On/Off
Power
LTETDD LTETDD:
BTS: External 1
MS: Periodic
Timer
LTETDD:
BTS: External
1
MS: Periodic
Timer
Transmit
Analysis
BLUETOOTH RFB IQ not
supported
Adjacent
Channel
Power
BLUETOOTH IMM IQ not
supported
LE In-band
Emissions
BLUETOOTH IMM IQ not
supported
EDR In-band
Spurious
Emissions
BLUETOOTH Periodic Timer IQ not
supported
Conformance
EVM
LTE, LTETDD,
MSR
IMM IMM
RF Trigger Source
The RF Trigger Source command selects the trigger to be used for the specified measurement when RF is
the selected input. The RF trigger source can be queried and changed even while another input is selected,
but it is inactive until RF becomes the selected input.
Note the inclusion of the <measurement> parameter in the command below. Because each measurement
remembers its own Trigger Source, the command must be qualified with the measurement name. Note
that for the Swept SA measurement this is not the case; for backwards compatibility, no <measurement>
parameter is used when setting the Trigger Source for the Swept SA measurement.
Remote Command
:TRIGger:<measurement>[:SEQuence]:RF:SOURce EXTernal1 | EXTernal2 |
IMMediate | LINE | FRAMe | RFBurst | VIDeo | IF | ALARm | LAN | TV
:TRIGger:<measurement>[:SEQuence]:RF:SOURce?
Example TRIG:ACP:RF:SOUR EXT1
Selects the external 1 trigger input for the ACP measurement and the RF input
