9 Strip Chart Measurement
Marker
Key Path
Marker
Example CALC:SCH:MARK:MODE POS Sets Marker 1 to Normal.
Couplings The marker addressed by this command becomes the selected marker on the front panel.
State Saved Saved in instrument state.
Initial S/W Revision A.07.00
Delta
Sets the control mode for the selected marker to Delta and turns on the active function for setting its delta
value. If the selected marker is off, the marker is placed at the center of the screen on the trace specified by
the marker’s Trace attribute.
In Delta mode the marker result shows the relative result between the selected (Delta) marker and its
reference marker. A delta marker can be moved to any point on the X Axis by specifying its X Axis offset
from a reference marker. Its absolute Y Axis value is then the value of the trace point at that X Axis value.
Key Path
Marker
Example CALC:SCH:MARK:MODE DELT Sets marker 1 to Delta.
Dependencies The marker addressed by this command becomes the selected marker on the front panel.
State Saved Saved in instrument state.
Initial S/W Revision A.07.00
Off
Turn off the selected marker. Remove marker annunciation from the display. Turn off any active function.
Tuning the marker off does not affect which marker is selected.
Key Path
Marker
Example CALC:SCH:MARK:MODE OFF Sets Marker 1 to Off.
State Saved Saved in instrument state
Initial S/W Revision A.07.00
Marker X Axis Value (Remote Command Only)
Sets the marker X Axis value in the current marker X Axis Scale unit. It has no effect if the control mode is
Off, but is the SCPI equivalent of entering an X value, if the control mode is Normal or Delta.
