9 Strip Chart Measurement
Marker
Marker
Accesses the Marker menu. The functions in this menu include a 1-of-N selection of the control mode
Normal, Delta or Off for the selected marker. If the selected marker is Off, pressing Marker sets it to Normal
and places it at the center of the screen on the trace determined by the Marker Trace rules. At the same
time, the reference value of the selected marker appears on the Active Function area.
The marker X axis value entered in the active function area will display the marker value to its full entered
precision.
Key Path
Front-panel key
Remote Command
:CALCulate:SCHart:MARKer[1]|2|...12:MODE POSition|DELTa|OFF
:CALCulate:SCHart:MARKer[1]|2|...12:MODE?
Example CALC:SCH:MARK:MODE OFF
CALC:SCH:MARK:MODE?
Notes If the selected marker is Off, pressing Marker sets it to Normal and places it at the center of the
screen on the trace determined by the Marker Trace rules. At the same time, Marker X Axis Value
appears in the Active Function area.
Default Active Function: the active function for the selected marker’s current control mode. Note
that if the current control mode is Off, there is no active function and the active function is turned off.
Active Function Display: the marker X axis value entered in the active function area will display the
marker value to its fully entered precision.
Preset OFF
State Saved Saved in instrument state
Initial S/W Revision A.07.00
Select Marker
Display a menu with 12 markers available for selection for the current measurement.
Key Path
Marker
Notes Front panel only. The selected marker is remembered even when not in the Marker menu and is used
Preset Marker 1
State Saved Saved in instrument state.
Initial S/W Revision A.07.00
Marker X Axis Value (Remote Command Only)
Sets the marker X Axis value in the current marker X Axis Scale unit. It has no effect if the control mode is
Off, but is the SCPI equivalent of entering an X value, if the control mode is Normal or Delta.
EMI Receiver Mode Reference 633
