8 Frequency Scan Measurement
Save
30540022.27 –90.66836416
30600024.74 –87.10931161
Strip Chart Trace File Content
The following file example shows the Trace file content in Excel.
AllTrace
EMI:SCHart
A.07.00_R0009 N9020A
526 EA3 B25 P26 PFR 1
Frequency 600000000
Freq Offset 0
Attenuation 10
Y Axis Unit dBuV
Ref Level Offset 0
Internal Preamp State Off
Internal Preamp Band Low
Resolution Bandwidth 120000
Dwell Time 0.05
Peak Hold Infinite
Peak Hold Time 2
Max Duration 500
Data
Trace 1 2 3
Detector Peak QuasiPeak EmiAverage
Max 25.4396633 20.242876 12.356569
0 23.7515958 20.173686 12.282337
–0.05 24.6648769 20.194918 12.262222
–0.1 23.3178199 20.213507 12.253423
–0.15 23.5216423 20.221337 12.258119
–0.2 23.4602343 20.220859 12.262763
–0.25 23.5765176 20.212508 12.297994
–0.3 23.7032533 20.197088 12.325791
–0.35 24.825583 20.185434 12.332104
550 EMI Receiver Mode Reference

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
