Keysight x-series User Reference Guide

5 Mode Functions
Mode Setup
Only one phase can be selected.
Initial S/W Revision A.13.50
150 kHz Highpass
Controls highpass setting on the V-network.
Key Path
Mode Setup, LISN Control, ENV216
Remote Command
INPut[1]|2:LISN:FILTer:HPAS[:STATe] ON|OFF|1|0
INPut[1]|2:LISN:FILTer:HPAS[:STATe]?
Example :INP:LISN:FILT:HPAS ON
Dependencies This key is grayed out when V-network other than ENV216 is selected. If the grayed out key is
pressed, an advisory message is generated. If the equivalent SCPI command is sent, this same
message is generated as part of a “–221, Setting Conflict; Function not available with current LISN
Type” warning.
Couplings This key is coupled to 150kHz Highpass of Frequency Scan Measurement’s LISN Control (Measure),
and vice versa.
Preset Set to off on a "Restore Input/Output Defaults"
State Saved Saved in instrument state
Range ON|OFF
Initial S/W Revision A.13.50
V-network
Enables you to select the V-network that is controlled via the AUX IO port.
Key Path
Mode Setup, LISN Control
Remote Command
INPut[1]|2:LISN[:TYPE] FOURphase|ESH2Z5| ENV216 | OFF
INPut[1]|2:LISN[:TYPE]?
Example :INP:LISN FOUR
Notes FOURPhase and ESH2-Z5
R&S ESH2-Z5 (four phases and protective earth are controllable)
ENV216
R&S ENV216 (two phases and highpass are controllable)
OFF
Remote control deactivated
This query will return :-
FOUR when ESH2-Z5 is selected.
Preset Set to off on a "Restore Input/Output Defaults"
State Saved Saved in instrument state
Initial S/W Revision A.13.50
EMI Receiver Mode Reference 263
