8 Frequency Scan Measurement
Meas Setup
Off
Pressing this key, turns the demodulation function off.
Key Path
Meas Setup, Analog Demod
Example :FSC:DEM OFF Turns off demodulation function.
State Saved Saved in instrument state.
Initial S/W Revision A.07.00
LISN Control (Measure)
This menu enables you to access LISN related functions. LISN control is only available in the MXE with
option LSN, which indicates the availability of IO board. Otherwise, the key will not be shown.
Key Path
Meas Setup
Initial S/W Revision A.13.50
V-network
This key enables you to select the V-network that is controlled via the AUX IO port in a final measurement.
Key Path
Meas Setup, LISN Control
Remote Command
:SENSe1|SENSe2|[SENSe]:FMEasurement:LISN[:TYPE] FOURphase | ESH2Z5 |
ENV216 | OFF
:SENSe1|SENSe2|[SENSe]:FMEasurement:LISN[:TYPE]?
Example FME:LISN FOUR
Notes FOURPhase and ESH2-Z5:
R&S ESH2-Z5 (four phases and protective earth are controllable)
ENV216:
R&S ENV216 (two phases and highpass are controllable)
OFF:
Remote control deactivated
Dependencies This key is grayed out when a scan sequence is running. If the grayed out key is pressed, an advisory
message is generated. If the equivalent SCPI command is sent, this same message is generated as
part of a “–221, Settings conflict” warning.
Preset OFF
State Saved Saved in instrument state
Initial S/W Revision A.13.50
504 EMI Receiver Mode Reference
