10 Monitor Spectrum Measurement
View/Display
Screen
This controls the display of the annunciation and annotation around the graticule, including any annotation
on lines (such as the display line, the threshold line, etc.) and the y-axis annotation. This does NOT include
marker annotation (or the NdB result). When off, the graticule expands to fill the entire graticule area,
leaving only the 1.5% gap above the graticule as described in the Trace/Detector chapter.
Key Path
View/Display, Display, Annotation
Remote Command
:DISPlay:ANNotation:SCReen[:STATe] OFF|ON|0|1
:DISPlay:ANNotation:SCReen[:STATe]?
Example DISP:ANN:SCR OFF
Dependencies Grayed-out and forced to OFF when System Display Settings, Annotation is set to Off.
Preset On
This should remain Off through a Preset when System DisplaySettings, Annotation is set to Off
State Saved Saved in instrument state.
Initial S/W Revision Prior to A.02.00
Trace
Turns on and off the labels on the traces, showing their detector (or their math mode) as described in the
Trace/Detector section.
If trace math is being performed with a trace, then the trace math annotation will replace the detector
annotation.
Key Path
View/Display, Display, Annotation
Remote Command
:DISPlay:ANNotation:TRACe[:STATe] ON|OFF|1|0
:DISPlay:ANNotation:TRACe[:STATe]?
Example DISP:ANN:TRAC OFF
Preset Off
State Saved Saved in instrument state.
Initial S/W Revision Prior to A.02.00
Active Function Values On/Off
Turns on and off the active function display in the Meas Bar, and all of the active function values displayed
on the softkeys.
Note that all of the softkeys that have active functions have these numeric values blanked when this
function is on. This is a security feature..
