Keysight x-series User Reference Guide

4 Input/Output Functions
Input/Output
Key Path
Input/Output, Output Config
Remote Command
:OUTPut:IQ:OUTPut IQ1|IQ250|OFF
:OUTPut:IQ:OUTPut?
Example OUTP:IQ:OUTP IQ1
Couplings An I/Q Cable Calibration or an I/Q Probe Calibration will change the state of the Cal Out port as
needed by the calibration routine. When the calibration is finished the I/Q Cal Out is restored to the
pre-calibration state.
Preset Off
State Saved Saved in instrument state
Range 1 kHz Square Wave|250 kHz Square Wave|Off
Readback Text 1 kHz|250 kHz|Off
Initial S/W Revision Prior to A.02.00
Aux IF Out
This menu controls the signals that appear on the SMA output on the rear panel labeled “AUX IF OUT
The Aux IF Out functionality is only valid for RF and External Mixer inputs. When using the External Mixing
path, the Aux IF Out levels (for all three Options CR3, CRP, and ALV) will be uncalibrated because the
factory default Aux IF level was set to accommodate the expected IF levels for the RF path.
Key Path
Input/Output, Output Config
Remote Command
:OUTPut:AUX SIF|AIF|LOGVideo|OFF
:OUTPut:AUX?
Dependencies The softkey does not appear in models that do not support the Aux IF Out.
Preset This is unaffected by a Preset but is set to OFF on a "Restore Input/Output Defaults" or "Restore
System Defaults->All”
State Saved Saved in Input/Output state
Readback line 1-of-N selection [variable]
Backwards Compatibility
Notes
In the PSA, the IF output has functionality equivalent to the "Second IF" function in the X-Series’ Aux
IF Out menu. In the X-Series, it is necessary to switch the Aux IF Out to “Second IF” to get this
functionality, whereas in PSA it is always on, since there are no other choices. Hence a command to
switch this function to “Second IF” will have to be added by customers migrating from PSA who use
the IF Output in PSA.
Initial S/W Revision A.04.00
Off
In this mode nothing comes out of the “AUX IF OUT” connector on the rear panel. The connector appears
as an open-circuit (that is, it is not terminated in any way).
EMI Receiver Mode Reference 207

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
