Function library
7-36
L
EDSVS9332P-D21 EN 3.0
Position resolution
•
Display via code C1205.
Display of the number of increments with which the units defined by the user are resolved
(incr/unit).
•
The position resolution can be used to check for rounding errors.
Calculation example:
C1301/1 = 100.2550 units (position value in VTPOS)
C1205 = 80.0000 inc/unit (position resolution)
Formula:
Feed = C1301[units] ⋅ C1205[inc∕unit]
8020, 4 inc = 100, 2550 units * 80, 0000 inc∕unit
A difference of 0.4 inc results from every feed.
Tip!
If it is not possible to have increments without decimal positions, drifting of the holding position can
be avoided by touch-probe positioning.
