Commissioning
5-6
L
EDSVS9332P-C EN 3.0
5.5 SwitchonPC,startGDC
•
Switch on PC.
•
Start the GDC program under Windows.
When GDC is in ”online operation”
•
The ”Find LECOM A/B drives” dialog box is opened.
•
Click ”Find”. GDC will now search for a controller.
•
GDC selects the first controller found.
•
GDC tests all baud rates which can be set.
•
GDC loads the parameter set description for the connected controller.
– If GDC does not find a parameter set description, you are asked which description you
want to load alternatively.
•
GDC automatically reads the parameter set from the controller.
When GDC is in ”offline operation”
•
You have to select the controller manually.
– You can change to ”online operation”. GDC automatically selects a controller.
•
Open the ”Controller” menu in the menu bar and click ”Select”.Makeyourchoicefor:
– the desired parameter set description.
– Baud rate.
– Controller address.
