Function library
7-235
L
EDSVS9332P-D21 EN 3.0
7.5.65.2 JOG setpoints
•
Are fixed values which are saved in the memory.
•
JOG values can be called from the memory via the inputs NSET-JOG*x.
•
The inputs NSET-JOG*x are binary coded so that 15 JOG values can be called.
•
The decoding for enabling the JOG values (called from the memory) is carried out according to
the following table:
Output signal 1st input
NSET-JOG*1
2nd input
NSET-JOG*2
3rd input
NSET-JOG*4
4th input
NSET-JOG*8
NSET-N 0 0 0 0
JOG 1 1 0 0 0
JOG 2 0 1 0 0
JOG 3 1 1 0 0
JOG 4 0 0 1 0
JOG 5 1 0 1 0
JOG 6 0 1 1 0
JOG 7 1 1 1 0
JOG 8 0 0 0 1
JOG 9 1 0 0 1
JOG 10 0 1 0 1
JOG 11 1 1 0 1
JOG 12 0 0 1 1
JOG 13 1 0 1 1
JOG 14 0 1 1 1
JOG 15 1 1 1 1
•
When all inputs are assigned with 0, the input NSET-N is active.
•
The number of inputs that must be assigned depends on the required number of JOG values.
Four inputs and thus 15 possible selections are available. A digital signal source is assigned
via C0787 and the corresponding subcode.
Number of required JOG setpoints Number of inputs to be assigned
1 at least 1
1 ... 3 at least 2
4 ... 7 at least 3
8 ... 15 4
