Lenze 9300 - CW;CCW-QSP Link (R;L;Q)

Function library
7-254
L
EDSVS9332P-D21 EN 3.0
7.5.72 CW/CCW-QSP link (R/L/Q)
Purpose
The FB links the input of the direction of rotation and the QSP function and is protected against open
circuit.
C0889/2
C0889/1
R/L/Q
R/L/Q-QSP
R/L/Q-R/L
R/L/Q-R
R/L/Q-L
C0885
C0886
Fig. 7-205 CW-CCW-QSP link (R/L/Q)
Signal
Source Note
Name Type DIS DIS format CFG List Lenze
R/L/Q-R d C0889/1 bin C0885 2 51 -
R/L/Q-L d C0889/2 bin C0886 2 52 -
R/L/Q-QSP d - - - - - -
R/L/Q-R/L d - - - - - -
Function
• After mains connection and simultaneous HIGH level at both inputs, the outputs are used as
follows:
Inputs Outputs
R/L/Q-R R/L/Q-L CW/CCW/Q-CW/CCW CW/CCW/Q-QSP
1 1 0 1
• The following table results, if the inputs were set to LOW once:
Inputs Outputs
R/L/Q-R R/L/Q-L CW/CCW/Q-CW/CCW CW/CCW/Q-QSP
0 0 0 1
1 0 0 0
0 1 1 0
1 1 unchanged unchanged
• If both inputs are set to HIGH during operation, both outputs still have their previously output
value.
