Function library
7-234
L
EDSVS9332P-D21 EN 3.0
Signal Source Note
Name Type DIS DIS format CFG List Lenze
NSET-N a C0046 dec [%] C0780 1 50 Intended for main setpoint, other signals
are permissible
NSET-NADD a C0047 dec [%] C0782 1 5650 Intended for additional setpoint, other
signals are permissible
NSET-JOG*1 d C0799/4 bin C0787/1 2 53
Selection and control of overri ding ”fixed
NSET-JOG*2 d C0799/5 bin C0787/2 2 1000
setpoints” for the main setpoint
NSET-JOG*4 d C0799/6 bin C0787/3 2 1000
NSET-JOG*8 d C0799/7 bin C0787/4 2 1000
NSET-TI*1 d C0799/8 bin C0788/1 2 1000
Selection and control of alternative ”fixed
NSET-TI*2 d C0799/9 bin C0788/2 2 1000
setpoints” for the main setpoint
NSET-TI*4 d C0799/10 bin C0788/3 2 1000
NSET-TI*8 d C0799/11 bin C0788/4 2 1000
NSET-N-INV d C0799/1 bin C0781 2 10251 Control of the signal inversion for the main
setpoint
NSET-NADD-INV d C0799/2 bin C0783 2 1000 Control of the si gnal inversion for the
additional setpoint
NSET-RFG-0 d C0799/12 bin C0789 2 1000 The main setpoint integrator is led to zero
via the current T
i
times.
NSET-RFG-STOP d C0799/13 bin C0790 2 1000 Keeping (freezing) of the main setpoint
integrator to its actual value.
NSET-CINH-VAL a C0798/1 dec [%] C0784 1 5001 Here, the signal is appli ed which is to be
accepted by the main setpoint integrator
when the controller is inhibited
NSET-SET a C0798/2 dec [%] C0785 1 5000 Here, the signal is applied which is to be
accepted by the main setpoint integrator
when the NSET-LOAD input is set
NSET-LOAD d C0799/3 bin C0786 2 5001 Control of both ramp function generators in
special situations, e.g. QSP
NSET-OUT a - - - - - -
NSET-RFG-I=0 d - - - - - -
Function
•
Main setpoint path
•
JOG setpoints
•
Setpoint inversion
•
Sramp
7.5.65.1 Main setpoint path
•
The signals in the main setpoint path are limited to the value range ±199.99 %.
•
The signal at input NSET-N is led via the function JOG selection.
•
The JOG function has priority over the setpoint input NSET-N. This means a selected JOG
value deactivates the input. The subsequent signal conditioning the JOG value instead.
