Lenze 9300 - Loading of the Ramp Function Generator

Function library
7-256
L
EDSVS9332P-D21 EN 3.0
7.5.73.1 Calculation and setting of the times T
ir
and T
if
The acceleration time and deceleration time refer to a change of the output value from 0 to 100 %.
The times T
ir
and T
if
can be calculated as follows:
100%
0
t
ir
t
if
T
ir
T
if
t
RFG1-OUT
[%]
w1
w2
T
ir
= t
ir
100%
w2 − w1
T
if
= t
if
100%
w2 − w1
Fig. 7-207 Acceleration and deceleration times of the ramp generator
t
ir
and t
if
are the times for the change between w
1
and w
2
The values for T
ir
and T
if
canbesetunder
C0671 and C0672.
7.5.73.2 Loading of the ramp function generator
The ramp function generator can be initialized with defined values via the inputs RFG1-SET and
RFG1-LOAD.
• As long as the input RFG1-LOAD = HIGH, the input RFG1-SET is switched to the output.
• If the input RFG1-LOAD = LOW, the ramp function generator accelerates from this value to its
input value along the set T
i
times.
