Lenze 9300 - Code Table

Configuration
7-323
L
EDSVS9332P-D22 EN 3.0
Part D2.2
7.8 Code table
How to read the code table:
Column Abbreviation Meaning
Code C0039
1
2
...
14
15
Code C0039
Subcode 1 of code C0039
Subcode 2 of code C0039
...
Subcode 14 of code C0039
Subcode 15 of code C0039
[C0005] Parameter value of the code can only be modified when the controller is inhibited
LCD Keypad LCD
Lenze Factory setting of the code
Æ The column ”Important” contains further information
0
Codes only display values. They cannot be configured.
Selection 1{1%}99Minimum value {smallest step/unit} maxi mum value
Important - Additional, important explanation of the c ode
Printed in bold: Code number in GDC
E 7-323 Reference on page with further information on the code.
Code Possible settings Important
No. LCD Len ze Selection
C0002 PAR LOAD 0
Load parameter set
0 Default setting Load factory setting into RAM
1 Load pset 1 Load parameter set 1 into the RAM and activate
it
Parameter set is loaded automatically after
every mains connection.
11 Load parameter set externally Load the parameter set 1 from the keypad into
theRAMandactivateit
20 ext. Æ EEPROM Load all parameter sets from the keypad into
theRAMandactivatethem
C0003 PAR SAVE 0
Save parameter set
0 Saving completed Saving completed
1 Save parameter set1 Save parameter set non-volatile
11 Save externally Transfer parameter set into the keypad
C0004 OP DISPLA Y 56 1 {1} 1999 Operating display
Keypad sho ws selected code in the operating
level if no other status messages of C0183 are
active.
