Lenze 9300 - Motor Phase Failure Detection (MLP)

Function library
7-226
L
EDSVS9332P-D21 EN 3.0
7.5.61 Motor phase failure detection (MLP)
Purpose
Motor phase monitoring.
MLP1
Fig. 7-174 Motor phase failure detection (MLP1)
Code
LCD
Possible settings
Important
o
Lenze Selection
p
o
C0597 MONIT LP1 3 0Trip
2 Warning
3Off
Conf. LP1
Configuration monitoring motor phase
failure
C0599 LIMIT LP 1 5.0 1.0 {0.1} 10.0 Current limit LP1
Current limit for motor phase failure
monitoring
Function
Detailed descriptions concerning monitoring / fault messages can be found in part E
(Troubleshooting and fault elimination) of the System Manual.
The function block MLP1 must be entered into the processing table if the motor phase failure
detection is to be used.
