Lenze 9300 - Page 511

Configuration
7-380
L
EDSVS9332P-D22 EN 3.0
Code ImportantPossible settings
No. SelectionLenzeLCD
C1720
0
-2147483647 {1} 2147483647
BCD3
1 OUTPUT SIGNAL
2 BCD RESULT
C1721 CODE 141 11 {1} 2000 BCD3
Code
C1722 SUBCODE 0 0 {1} 255 BCD3
Subcode
C1723 NUMERATOR 1 0 {1} 100000 BCD3
Numerator
C1724 DENOMINATOR 0.0001 0.0001 {0.0001} 100000.0000 BCD3
Denominator
C1725 OFFSET 0 0 {1} 1000000000 BCD3
Offset
C1726 BCD MODE 0 0
1
no hand-shake
with hand-shake
BCD3
Mode
C1727 BCD DELAY 10 0 {1 ms} 255 BCD3
Select deceleration
[C1728] → Selection list 2
BCD3
1 READ 1000 FIXED0
Configuration - digital input signals
2 DATA1 1000 FIXED0
3 DATA2 1000 FIXED0
4 DATA3 1000 FIXED0
5 DATA4 1000 FIXED0
6 LOAD 1000 FIXED0
7 BUSY-IN 1000 FIXED0
8 FAIL-IN 1000 FIXED0
C1729
0
0 1
BCD3
1 READ
2 DATA1
3 DATA2
4 DATA3
5 DATA4
6 LOAD
7 BUSY-IN
8 FAIL-IN
C1799 DFOUT F
MAX
[KHZ] 1250 20 {1} 1250 DFOUT f
max
(kHz)
