Chapter 7: Diagnostics and Maintenance
MP65492–1 147 Linx 4900 Operating Manual
The procedure for cleaning the printhead varies according to the type of
ink being used in the printer—non-pigmented ink or pigmented ink.
For Printers Using Non-pigmented
and
Pigmented
Inks:
To clean the printhead, do the following:
1. Ensure that the printer is in the “Jet Off” state. To verify this, check the
Status in the PRINT STATUS screen.
2. Unscrew the securing screw of the printhead’s cover tube and slide off
the cover. The printhead is hermetically sealed, so there is no risk of
cleaning fluids affecting any of the electrical connections.
3. Hold the printhead as shown in Figure 7-15 below, or mount it on a
wash station if you have one.
Figure 7-15 Cleaning the Printhead
Ensure that the cleaning solvent corresponds to the solvent type being
used in the printer.
49298
ULTIMA
WASH THIS
AREA ONLY
4900 Op Manual.book Page 147 Tuesday, September 9, 2003 12:32 PM
