215575 53 Revision B
Figure 3.56: Header Opening – Gleaner
®®
R and
S Series
Figure 3.57: Feeder House Saddle – All AGCO
Combines except Gleaner
®®
R and S Series
Figure 3.58: Feeder House Saddle – Gleaner
®®
R and
S Series
6. Raise the feeder house, ensuring that feeder house
saddle (A) and the alignment pins are properly engaged in
the header frame.
7. Position the header slightly off the ground, stop the engine,
and remove the key from the ignition.
OPERATION
