Operating elements for driving
3.2 Brief description of the operating elements
Operating Instructions GMK5250L 3 302 633 en 3 - 47
27.09.2017
Setting the Tempomat
The truck crane must be driving at a speed at
least 15 km/h (9 mph).
Setting the Temposet
The truck crane must be driving at a speed at
least 15 km/h (9 mph).
Instrument panel
Tachometer
2 Select the
Cruise control menu – symbol (1)
is grey
3 Switches on or increases the speed –
symbol (1) is white
4 Switches on or reduces the speed
5 Switching off
à p. 5 - 39
1
Select Temposet – symbol (2) is grey
3 Switches on or increases the speed limit –
symbol (2) is white
4 Switch off or reduce the speed limit
5
Switch Temposet off
à p. 5 - 40
Display, engine speed in rpm; Ã p. 4 - 19
