Rigging work
11.8 Outrigger operation
Operating Instructions GMK5250L 3 302 633 en 11 - 39
27.09.2017
11.8.2 CHECKLIST: Retracting the outriggers
H
This checklist is not a complete operating manual. There are accompanying
instructions, which are indicated by cross-references.
Observe the warnings and safety instructions there!
1. Retract the outrigger cylinders as far as possible;
à p. 11 - 53.
2. Move the outrigger pads into the driving position and secure them;
à Moving into driving position, p. 11 - 51.
3. Fully retract and secure all outrigger beams;
à For on-road driving, p. 11 - 44,
à Extending/retracting outrigger beams, p. 11 - 45.
4. Stow away packing material safely, if applicable.
5. Activate the suspension (release locking).
The symbol must be green (suspension on);
à p. 5 - 16.
s
