Driving modes and rigging for on-road driving
6.5 Installing/removing the outrigger beams
6 - 36 3 302 633 en Operating Instructions GMK5250L
27.09.2017
6.5.1 CHECKLIST: Removing the outrigger beams
H
This checklist is not a complete operating manual. There are accompanying
instructions, which are indicated by cross-references.
Observe the warnings and safety instructions there!
1. Preparing the truck crane
– For removal using an auxiliary crane;
à p. 6 - 40.
– For removal using the truck crane;
à p. 6 - 41.
2. Label the outrigger beams, retract, release and bolt them to each other;
à p. 6 - 40.
3. If necessary remove outrigger pad;
à p. 6 - 43.
4. Unscrew the spacer;
à p. 6 - 47.
5. – Disconnect the hydraulic connections;
à p. 6 - 45.
– Separate the electrical connection if necessary;
à p. 6 - 46.
