Operating elements for driving
3.2 Brief description of the operating elements
Operating Instructions GMK5250L 3 302 633 en 3 - 59
27.09.2017
3.2.11 Final drive
à Longitudinal and transverse differential locks, p. 5 - 50
Driving menu
Transverse differential locks on/off
When a symbol (1) is selected both transverse differential locks are
switched on or off.
Transverse differential locks display
The current status is shown using different
symbols:
s
To open: Select symbol (1) and confirm – menu is opened
– To switch on: Select symbol (1) and confirm – symbol is red
– To switch off: Select symbol (1) and confirm – symbol is green
1 green – locks off
2red – locks on
3 yellow – intermediate position
4 violet – error
à p. 5 - 50
