Driving modes and rigging for on-road driving
6.4 Rigging the main boom
Operating Instructions GMK5250L 3 302 633 en 6 - 15
27.09.2017
6.4 Rigging the main boom
This section applies only to truck crane which are fitted with the pulling
devices for removing/mounting the main boom.
Additional equip-
ment required
In addition to the pulling devices, you also need the following accessories:
– a tightening belt (3),
– a lifting device (2),
– lifting gear (1),
as well as
– an auxiliary crane with sufficient lifting
capacity,
– a separate vehicle with sufficient load
bearing capacity and loading area.
Transport dimensions and weight;
à p. 1 - 10.
G
Risk of accident when removing/installing the main boom without pulling
devices
Only remove or install the main boom if the truck crane is equipped with
the factory-installed pulling devices and with the necessary accessories.
Without this factory-installed pulling device, the main boom may only be
removed by
Manitowoc Crane Care.
