Malfunctions in driving mode
7.3 Warning and error messages
Operating Instructions GMK5250L 3 302 633 en 7 - 11
27.09.2017
7.3.3 Warning messages on the CCS display
A warning message indicates that certain
values do not correspond to a target value
When CCS detects a fault then the display
area (1) shows an error or warning symbol.
Meaning of the symbols
The colour of the symbols indicates whether a warning or malfunction
message is active in the corresponding area.
– Symbol yellow – malfunction.
– Symbol red – warning message.
– no symbol – no malfunction or warning message.
If a symbol is displayed in red or yellow, perform the following checks.
Symbols in the
display area
Voltage monitoring
The voltage in the carrier electrical system is too high or too low.
Current voltage display;
à p. 4 - 16.
s
S
Risk of damage if warning messages are disregarded!
Observe the following information in good time and take the appropriate
remedial measures if a warning message appears. This prevents these
malfunctions causing defects in the truck crane.
