Malfunctions in driving mode
7.5 Emergency operation and breakdown assistance
7 - 26 3 302 633 en Operating Instructions GMK5250L
27.09.2017
7.5.2 Battery charger
Prerequisites – The engine must not be running and must be secured against unau-
thorised use,
– An external 230 V mains power supply must be available at the location,
– The location must be well ventilated and protected against moisture.
Connecting
• Insert the plug (1) into the socket (2).
• Place the battery charger (5) in a protected
place where you can see the indicator
lamp (3).
The battery charger can be suspended from
the ring eyes (4).
• Insert the plug (6) into the socket on the
mains supply 230 V at the location.
The battery charger switches on. The lamp (3)
on the battery charger indicates the status:
Disconnecting
• Pull the plug (3) out of the socket.
• Pull the plug (1) from the socket (2).
• Close the socket (2).
• Stow the battery charger.
G
Risk of explosion when operating the battery charger!
The battery charger may not be operated:
– at service stations and tank farms,
– at places where flammable gases or vapours can be found or formed
(e.g. at places where fuel is stored and in chemical factories),
– at places where explosive dust can be found or formed (e.g. carbon dust,
wood dust and grain dust).
– Flashing: The battery is being charged
– lights up: Charging complete
