Malfunctions in driving mode
7.6 Fuses
Operating Instructions GMK5250L 3 302 633 en 7 - 37
27.09.2017
7.6 Fuses
The fuses are divided into groups and are at various points on the carrier:
– In the driver's cab,
– In the battery box.
Information on
replacing fuses
The positions of the fuses, their designations and which functions are
protected by the respective fuses are shown in the following sections.
• Switch off the ignition whenever a fuse has to be replaced.
S
Risk of damage if the ignition is switched on!
Switch off the ignition whenever a fuse has to be replaced. This prevents
the new fuse being blown immediately by the increased starting current
after being installed.
S
Risk of damage by overloading!
Replace blown fuses only with new fuses of the same amperage. This pre-
vent parts being overloaded and damaged or the fuse being immediately
blown again.
If a fuse with the same amperage fails again once the ignition is switched
on, then notify
Manitowoc Crane Care.
S
Risk of fire!
Never repair a blown fuse with other electrically conductive materials.
