Crane operation
10.8 Work break
Operating Instructions GMK5250L 3 302 633 en 10 - 145
27.09.2017
10.8 Work break
10.8.1 In case of short work breaks
•
Switch off the slewing gear.
– The lamp in the button (1) must be dimly lit.
– The symbol (2) is red – slewing gear switched off.
– Lamp (3) must light up – slewing gear brake applied.
Switch the engine off, turn the ignition key to position 0 and remove it.
Ensure that no unauthorised persons can operate the truck crane;
à To secure the truck crane, p. 10 - 146.
G
Risk of accidents due to suspended loads!
Never switch off the engine whilst a load is suspended. You must have the
control levers at hand in order to intervene at any time.
Always set down the load before you leave the crane cab.
