Driving
5.3 Driving and parking off the truck crane
5 - 48 3 302 633 en Operating Instructions GMK5250L
27.09.2017
5.3.8 Folding berth
The berth must always be folded up for driving.
Folding down
• Place the steering column forwards, upright;
à Steering column adjustment, p. 5 - 14.
• Move the seats to their lowest position:
–
à Driver's seat, p. 5 - 12;
–
à Passenger's seat, p. 5 - 13.
• Remove the neck-rests from the seats and
tilt the back rests of the seats forwards.
• Release the berth (1) from the retainer (4)
and fold it downwards
• Fasten both belts (3) in the retainers (2).
Folding up
• Release the belts (3) from the retainers (2)
and place them on the berth.
• Fold up the berth (1) and fasten it in the
retainer (4).
• Put up the back rests of the seats and fasten
the neck-rests.
• Bring the seats and the steering column into
the desired position:
–
à Driver's seat, p. 5 - 12;
–
à Passenger's seat, p. 5 - 13;
–
à Steering column adjustment, p. 5 - 14.
G
Risk of accidents due to the berth folding down!
Check that the locking bar has engaged and put up the back rest of the seats
before driving. This prevents the berth from folding down when braking,
resulting in uncontrolled manoeuvres due to fright.
