Starting/switching off the engine – for crane operation
9.1 When starting the engine for the first time in the day
9 - 2 3 302 633 en Operating Instructions GMK5250L
27.09.2017
9.1.1 Checking the fuel level and AdBlue (DEF) level
• Check the fuel level, and the AdBlue (DEF) level if necessary, before
starting the engine.
After switching on the ignition the display shows the start menu.
Fuel
The display (1) indicates the current filling
level in percent.
With a standard tank, 100% corresponds to
approx. 700 l (184 gal).
à Dual tank, p. 4 - 8
The display changes colour depending on the
filling level:
AdBlue (DEF)
The display (1) indicates the current filling
level in percent.
100% corresponds to approx. 40 l (10.6 gal).
The display changes colour depending on the
filling level:
Green: over 10% (over 70 l) (18.4 gal)
Yellow: 5 to 10% (35 to 70 l) (9.2 to 18.4 gal)
Red: below 5% (less than 35 l) (9.2 gal)
Green: over 10% (over 4 l) (1.1 gal)
Yellow: 5 to 10% (2 to 4 l) (0.53 to 1.1 gal)
Red: below 5% (less than 2 l) (0.53 gal)
