Crane operation
10.1 Before operating the crane
10 - 8 3 302 633 en Operating Instructions GMK5250L
27.09.2017
10.1.3 Adjusting the crane cab seat and front control panel
Crane cab seat You can adjust the crane cab seat to your height.
Version 1
Version 2
1 Control panel right – height
2 Control panel left – height
3 Back rest – angle
4 Seat – height
5 Seat – longitudinal adjustment,
With control panels
6 Seat – longitudinal adjustment,
Without control panels
7 Seat cushion – angle
1 Control panel right – height
2 Control panel left – height
3 Back rest – angle
4 Seat heating
1)
on/off
5 Seat – height
1)
6 Seat – longitudinal adjustment,
With control panels
7 Adjust suspension stiffness to body
weight
8 Seat – longitudinal adjustment,
Without control panels
9 Seat cushion – angle
10 Upper lumbar area support
11 Lower lumbar area support
1)
Requirement – ignition is on
