Transportation
13.1 Transport with transport vehicle
Operating Instructions GMK5250L 3 302 633 en 13 - 1
27.09.2017
13 Transportation
Transport should be carried out only by qualified heavy transport compa-
nies whose personnel are well-acquainted with loads of these dimensions
and weights.
13.1 Transport with transport vehicle
• Note the dimensions and weight of the truck crane for the transport;
à Dimensions and weights of the truck crane, axle loads, p. 1 - 8.
G
Risk of accidents due to improper transport!
Assign transportation to only qualified companies and ensure that the reg-
ulations applicable in the country in which you are working are adhered to.
G
Risk of accidents due to improper means of transport!
Use only suitable lifting gear with sufficient lifting capacity for loading.
Use only trailers and vehicles with sufficient loading surface and carrying
capacity for transport.
G
Risk of accidents due to inadequate information!
Observe the information in the following sections concerning transport.
You can thus prevent unsecured parts from falling or components from
being damaged due to improper handling.
G
Risk of accidents!
Using only a suitable ramp of sufficient load bearing capacity. The ramp
inclination must not be greater than 15°.
If the inclination is too steep, unwanted motion of the vehicle may occur.
This can cause the truck crane to tip off the ramp. This can cause serious
injuries to yourself and other people.
G
Risk of accidents due to falling parts!
Use only suitable lifting gear with sufficient load bearing capacity and use
only the slinging points and lashing points provided.
