Driving modes and rigging for on-road driving
6.4 Rigging the main boom
Operating Instructions GMK5250L 3 302 633 en 6 - 33
27.09.2017
6.4.9 Transporting the main boom
Transport the main boom only on a separate vehicle which is of sufficient
size and has sufficient lifting capacity.
Transport dimensions and weight;
à Operating Instructions.
• Always place the main boom onto a suitable packing!
• Secure the main boom against slipping using the holding ropes.
• Load the main boom in such a way that other road users are not put at
risk.
• Load the transport vehicle in such a way that the weight is evenly
distributed.
• Secure the connection lines so that they will not slip and be damaged
during transport.
• Keep the connecting points free of contamination.
S
Risk of damage to the main boom!
Always place the main boom onto a suitable packing. If you lay the main
boom on its side, add-on parts will be damaged.
