Operating elements for driving
3.2 Brief description of the operating elements
3 - 74 3 302 633 en Operating Instructions GMK5250L
27.09.2017
3.2.17 Tachograph/speedometer
à Setting the tachograph, p. 5 - 17.
Tachograph Time correction occurs for both the Tachograph and on-board computer
Cover Time correction
Speedometer
Speed indicator
Kilometre counter
The ignition must be switched on.
1 Open the time menu: Press the button – the time correction menu
opens
2 Time correction +: Press the button – the time is increased
3 Time correction –: Press the button – the time is decreased
1 Time correction +: Press the button – the time is increased
2 Time correction –: Press the button – the time is decreased
1 Indicates the speed in km/h
2 Indicates the speed in mph
1 Overall distance travelled in kilometres – value after the decimal point:
1 = 100 m
2 Daily distance travelled in kilometres – value after the decimal point:
1 = 100 m
