Driving modes and rigging for on-road driving
6.6 Rigging the auxiliary hoist
Operating Instructions GMK5250L 3 302 633 en 6 - 63
27.09.2017
6.6.9 Creating the connection to the turntable
The respective button combination required is shown in black.
Establishing a
connection
Lifting the auxiliary hoist
• Press the buttons (3) and (4).
Press the button (2) until the locking points (1)
align.
s
G
Risk of being crushed when rigging the auxiliary hoist!
Make sure that you or any helpers keep all parts of the body a sufficient
distance away from the auxiliary hoist when rigging the auxiliary hoist.
Remove all objects in the rigging range that could become jammed or
crushed.
