Driving modes and rigging for on-road driving
6.6 Rigging the auxiliary hoist
6 - 64 3 302 633 en Operating Instructions GMK5250L
27.09.2017
Extending the locking cylinders
• Press the button (2) until the locking
cylinders (1) are fully extended.
• Close the safety valve (3) – lever at right
angles to the line.
Lifting the lifting frame
• Press the buttons (2) until the lifting
frame (1) is fully retracted.
G
Risk of accident when the safety valve is open!
Always close the safety valve when the auxiliary hoist is locked to the
turntable.!
This prevents the auxiliary hoist from falling down due to unintentional
actuation of the locking cylinders.
