1.5 Technical data
1 - 10 3 302 633 en Operating Instructions GMK5250L
27.09.2017
1.5.4 Dimensions and weights of removable parts
This section contains the dimensions and weights of the parts which can be
removed for on-road driving;
à Driving modes, p. 6 - 1.
Spare wheel
Outrigger
Designation
Length x width x height
in m (ft)
Weight in kg
(lbs)
Spare wheel 385/95 R 25 1.36 x 1.36 x 0.40
(4.45 x 4.45 x 1.30)
245
(540)
Spare wheel 445/95 R 25 1.50 x 1.50 x 0.45
(4.95 x 4.95 x 1.50)
310
(685)
Spare wheel 525/80 R 25 1.50 x 1.50 x 0.53
(4.95 x 4.95 x 1.74)
355
(785)
Designation
Length x width x height
in m (ft)
Weight
in kg (lbs)
Plastic outrigger pad
diameter
0.60 x 0.18
(1.97 x 0.59)
38
(84)
Front outrigger
1)
,
complete per packet
2.95 x 0.32 x 1.05
(9.68 x 1.05 x 3.44)
1,000
(2,205)
Rear outrigger
1)
,
complete, per packet
2.98 x 0.37 x 1.06
(9.78 x 1.21 x 3.48)
1,250
(2,756)
1)
Consists of two sets
