Malfunctions in driving mode
7.4 Troubleshooting
Operating Instructions GMK5250L 3 302 633 en 7 - 23
27.09.2017
7.4.6 Malfunctions of the differential locks
7.4.7 Malfunctions in the hydraulic system/hydraulic oil cooler
Malfunction Cause Remedy
Differential locks cannot be
switched on
Current speed over approx.
5 km/h (3 mph)
Slow down or stop the
truck crane
Drive train under tension Slowly drive truck crane
back and forth,
à p. 5 - 50
Compressed air system
insufficiently filled
à Building up supply pres-
sure
, p. 5 - 10
Fuses F2/1, F4/6, F5/4, F5/7
blown
Replace blown fuses;
à p. 7 - 38
Differential locks cannot be
switched off
Current speed over approx.
5 km/h (3 mph)
Slow down or stop the
truck crane
Drive train under tension Slowly drive truck crane
back and forth,
à p. 5 - 50
Error symbol is displayed CCS malfunction Note the error code
(
à p. 7 - 11) and notify
Manitowoc Crane Care
Malfunction Cause Remedy
Hydraulic oil temperature
above 80 °C, fan in the
hydraulic oil cooler is running
Hydraulic system under
extreme strain and ambient
temperature very high
Stop the truck crane while tak-
ing the traffic situation into
account and run the engine
until the oil has cooled down
Hydraulic oil temperature
above 80 °C, fan in the
hydraulic oil cooler is not
running
Fuse F1/3 blown Stop the truck crane while tak-
ing the traffic situation into
account, and replace the
blown fuse;
à p. 7 - 38.
Defective temperature sensor
in the hydraulic system (error
message is displayed)
Have the temperature sensor
replaced
