Starting the engine for driving / switching it off
4.1 Starting the engine from the driver's cab
Operating Instructions GMK5250L 3 302 633 en 4 - 5
27.09.2017
Ladders There are different ladders on the truck crane.
There are fold-out access ladders on the right-hand and left-hand side.
Folding out
• Unlock the spring latch (1).
• Turn the ladder (3) outwards and fold it
down.
• Secure this with the spring latch (2).
If necessary, you can pull out an additional
step (5) from the ladder.
• Unlock the spring latch (4) and pull out the
step (5).
Folding in
• Unlock the spring latch (4) and slide in the
step (5).
• Unlock the spring latch (2) and pivot the
ladder (3) onto the carrier.
• Secure this with the spring latch (1).
s
G
Risk posed by ladders falling down!
Always secure the ladders before driving. The prevents the ladders from
falling down while driving and endangering other vehicles.
