Driving
5.1 Before driving
Operating Instructions GMK5250L 3 302 633 en 5 - 9
27.09.2017
Warning plates for
vehicle width
Depending on the vehicle width, fold-up warning plates are fitted below the
driver's cab.
The warning plates (1) must be folded down
to indicate the vehicle width during on-road
driving.
For off-road driving, the warning plates can
be folded up and fastened with the locking
bar (2).
Displaying
vehicle height
The vehicle height given at on-road driving level is only maintained when
the main boom is resting in the boom rest;
à p. 1 - 8.
• Open the start menu.
With additional equipment the position of the main boom in the boom rest
is monitored.
• Check that the symbol (1) is shown.
• When the symbol (1) is shown, derrick the main boom out until the
symbol (1) disappears.
s
S
Risk of accidents by exceeding total permissible height!
Check that the symbol is displayed.
Otherwise the indicated total height will also be exceeded at on-road level.
