Driving
5.5 Separate steering
5 - 60 3 302 633 en Operating Instructions GMK5250L
27.09.2017
• Open the Driving menu (1).
• Select and confirm the symbol for the
desired steering mode.
– The symbol (4) is displayed – separate steer-
ing switched on.
– The symbols (5) are red – steering unlocked.
H
When separate steering is switched on, the speed is limited to approx.
20 km/h (12 mph).
If the error symbol is displayed, contact
Manitowoc Crane Care.
Manual
• Steer the 1st to 3rd axle lines with the steering wheel.
• Steer the 4th and 5th axle lines with the button (1).
The axle lines are steered as long as you keep the button pressed or until an
end position is reached.
1 Crab travel mode, 4th and 5th axle line
steered automatically
2 driving around corners, 4th and 5th
axle line steered automatically
3 Manual, 4th and 5th axle line is steered
manually for driving around corners/
crab travel mode
– To turn to the left: • Push the button to the left.
– To turn to the right:
• Push the button to the right.
