Driving modes and rigging for on-road driving
6.5 Installing/removing the outrigger beams
6 - 52 3 302 633 en Operating Instructions GMK5250L
27.09.2017
• Lift the outrigger beam as far as possible
into the outrigger box.
Correct the height so that it does not remain
hanging on the edges (1).
• Remove the lifting gear from the centre of
gravity.
• Fasten the lifting gear (1) and a chain hoist.
• Fasten the chain hoist with a suitable
mounting device on the bore hole (2).
• Pull the outrigger beam in so far until the
connecting points (1) align.
• Remove the chain hoist and lifting gear.
