Manitowoc Grove GMK 5250L

Operating elements for crane operation
8.1 Overview of the operating elements
Operating Instructions GMK5250L 3 302 633 en 8 - 57
27.09.2017
Telescoping
emergency
program menu
s
XXX sec
XXXX mm
#1
#2
XXXX mm
1 Input access code emergency program à p. 14 - 29
2 Remaining time emergency program display
à p. 14 - 29
3 Telescoping cylinder length display
à p. 14 - 29
4 Proximity switch display
à p. 14 - 29
5 Locking status telescoping cylinder display
à p. 14 - 29
6 Symbol lock/release telescoping cylinder
à p. 14 - 29
7 Locking status telescopic section display
à p. 14 - 29
8 Symbol lock/release telescopic section
à p. 14 - 29
