Operating elements for crane operation
8.2 Brief description of the operating elements
8 - 114 3 302 633 en Operating Instructions GMK5250L
27.09.2017
CCS display
Power units display
Slewing gear brake applied/released display
–Green: Slewing gear on
–Red: Slewing gear off
1On: Slewing gear brake applied
1 Off: Slewing gear brake released
à p. 10 - 115
