Crane operation
10.1 Before operating the crane
Operating Instructions GMK5250L 3 302 633 en 10 - 19
27.09.2017
Switching off the
houselock
• Check that the slewing gear is switched off, and switch if off if necessary;
à Switching off the slewing gear, p. 10 - 17.
• Select the symbol (4).
• Press the button until the symbol (3) is dis-
played –
Houselock switched off.
The display first shows the symbol (1), then
symbol (2) in the intermediate position and
then symbol (3) when the houselock is
switched off.
S
Risk of damage during slewing!
Always switch off the slewing gear before you operate the houselock. The
system will be damaged if the superstructure is slewed during the locking
procedure.
To Next Page
