Operating Instructions GMK5250L 3 302 633 en 1 - 13
27.09.2017
Auxiliary hoist
Counterweight
sections
The stability of the crane rigged with the counterweight sections delivered
has been tested.
Designation
Length x width x height
in m (ft)
Weight
in kg (lbs)
Complete auxiliary hoist 1.15 x 1.90 x 0.80
(3.77 x 6.23 x 2.62)
2,000
(4,410)
Rigging frame 1.43 x 2.17 x 0.55
(4.69 x 7.12 x 1.80)
352
(776)
Designation
Length x width x
height in m (ft)
Weight
in kg
1)
(lbs)
7 t base plate 2.99 x 2.37 x 1.25
(9.81 x 7.78 x 4.10)
7,000
(15,432)
9.5 t plates, each 2.99 x 2.40 x 0.29
(9.81 x 7.87 x 0.95)
9,500
(20,950)
9.5 t section with cutouts 2.99 x 2.40 x 0.29
(9.81 x 7.87 x 0.95)
9,500
(20,950)
4.75 t plates (left and right),
each
1.05 x 2.37 x 0.41
(3.44 x 7.78 x 1.35)
4,750
(10,472)
4.75 t plate (middle) 1.33 x 2.31 x 0.33
(4.36 x 7.58 x 1.08)
4,750
(10,472)
each 5 t block 1.41 x 1.22 x 0.79
(4.63 x 4.00 x 2.59
5,000
(11,023)
10 t block, each 1.97 x 0.97 x 1.30
(6.46 x 3.18 x 4.27
10,000
(22,046)
1)
There may be deviations of up to ± 3% due to the manufacturing
procedure.
