Crane operation
10.5 Crane operation with main boom
10 - 110 3 302 633 en Operating Instructions GMK5250L
27.09.2017
Telescoping with
semi-automaton
When telescoping with semi-automation, you enter the desired fixed
lengths and then move the control lever in the required direction. Switching
between the telescopic sections is carried out automatically by CCS.
H
If the desired telescoping status is not a fixed length, you can first telescope
to the next closest fixed length with the semi-automation and then tele-
scope further to the desired length manually.
• Switch on the telescoping mechanism;à p. 10 - 89.
• Open the Telescoping semi-automation menu (1).
Entering the telescoping status
You can cancel the input at any time – press
button (10) or (11) once.
Entry for all telescopic sections
• Select and confirm the desired value (7).
Entry for individual telescopic sections
• Select and confirm the desired value (1)
to (6).
– Display symbol (9) – telescoping not
permitted – enter a new value.
– Display symbol (8) – telescoping permitted –
the entry can be confirmed.
